VA CE steel percussion anchor

Assesment for non-cracked concrete
vorpa en p417542-va-ce-steel-percussion-anchor 010
VA CE with internal thread. Option 7 for non-cracked concrete. Stainless steel and INOX A4 versions available
VA F lipped type with o without ETA - photo 1

SUPPORT MATERIALS

vorpa en p417542-va-ce-steel-percussion-anchor 013
Non cracked concrete
vorpa en p417542-va-ce-steel-percussion-anchor 014
Solid base material
vorpa en p417542-va-ce-steel-percussion-anchor 015
Natural stone
vorpa en p417542-va-ce-steel-percussion-anchor 016 = Suitable application vorpa en p417542-va-ce-steel-percussion-anchor 017 = after checking the consistency of the base material

Certifications

vorpa en p417542-va-ce-steel-percussion-anchor 018
vorpa en p417542-va-ce-steel-percussion-anchor 019
vorpa en p417542-va-ce-steel-percussion-anchor 020
vorpa en p417542-va-ce-steel-percussion-anchor 021

Suitable to fix

  • Railings
  • Plants engineering
  • Beams
  • Sections
  • Ventilation systems and ceiling heating systems
  • Ceiling lighting
Versions:
  • Zinc-plated steel
  • A4 stainless steel​

Benefits:
  • Steel anchor with internal thread and internal expansion cone to be used with bolts or threaded bars.
  • When the cone is driven in with the apposite impacting tool, the anchor sleeve is spread and thus expands against the hole wall.
  • Easy application and quick and safe installation thanks to the proper impacting tool
  • The collar of the lipped type avoid the slipping of the anchor inside the hole
  • Suitable for bars and accessories with metrical thread
  • Possibility of inserting the anchor through the object to be fxed
  • Low anchorage depth reduces drilling time and thus cost-effcient installation
  • Surface-fush anchor allows the attached items to be removed and reftted several times.​

Approved for:
  • Non-cracked concrete C20/25 to C50/60​

Also suitable for:
  • Non cracked concrete C12/15
  • Natural stone with dense structure​

Installation:
  • Pre-setting anchor
  • Through-setting only in the version VA​

Suggestions for use:
  •  Choose the most suitable accessory in relation to the application to carry out
  • Choose the right size of the anchor according to the load
  • Always check load bearing capacity values in the table
  • Respect the installation data
  • Clean the hole before the installation

VA CE steel percussion anchor
