Products » Cladding and pipe fixings » Cable fixings

CABLE TIE FZ

 Black or white coloured cable tie
black cable tie
natural cable tie - photo 1
Download
vorpa en p436403-cable-tie-fz 010 Data sheet
vorpa en p436403-cable-tie-fz 011 = Suitable application vorpa en p436403-cable-tie-fz 012 = after checking the consistency of the base material

Suitable to fix

  • Electrical installations
  • Industrial wiring
  • Automotive
  • Panel buildings
  • Special applications
  • DESCRIPTION
  • vorpa en p436403-cable-tie-fz 013REQUEST INFO
Characteristics:
  • Material:Polyamide 6.6
  • Humidity absorption:2,7% (50% relative humidity)
  • Working temperature -40°C ÷ 85°C
  • Tightening temperature -10°C ÷ 60°C
  • Max admissable point +110°C for short time
  • Melting temperature+256°C
  • Limit Oxygen Index (LOI):27%
  • Flammability rating:UL 94 class V2
  • Tested according to EN 50146
  • High resistance to bases, oils, greases, oil derivatives
  • Limited resistance to acids
  • Not resistant to phenols and to chloride solvents
  • Halogen-free resins
  • UV resistance (black color)​

Benefits:
  • Smooth rounded edges make them easier to be handled and safer to be installed
  • Bent rounded tip allows easier insertion through the head of the cables ties
  • Low friction coeffcient of the material
